NEXT-GENERATION DAC 10G SFP+ 3 Meters Fiber Optic Cable - Black

Next-Gen Direct Copper Cable Assemblies are designed for Infiniband 10 Gigabit Ethernet and 40 Gigabit Ethernet applications. These cable assemblies provide four channels of data in one pluggable interface.

Each channel is capable of transferring data at 10Gbps and supports a total of 40 Gbps data rate. And meet all IBTA, QSFP MSA and SFF-8436 ,Infiniband QDR specification requirements. Compare with fiber optical cable assemblies, SFP+ direct copper cable provide a cost-effective solution in data center short reach interconnects applications.

Product Features

• Data Rate: Up to 10 Gb/s
• Transceivers: SFP+ TO SFP+
• Cable Length: 3 Meters
• Cable Diameter: 30AWG
• Cable Color: Black

Product Detail

✔ Support for multi-gigabit data rates up to10Gb/s

✔ Data rates backward compatible to 1Gb/s

✔ Hot-pluggable SFP 20PIN footprint

✔ Improved Pluggable Form Factor(IPF) Compliant for enhanced EMI/EMC performance

✔ Low Power Consumption < 0.2W

✔ Power Supply :+3.3V

✔ Compatible to SFP+ MSA

✔ Compatible to SFF-8431,SFF8432

✔ Temperature Range: 0~ 70 °C

✔ RoHS Compatible

Wide Compatibility

✔ For Next-Gen, Cisco, Fortinet, Ubiquiti, Netgear, D-Link, TP-Link, Linksys, Broadcom, Edge-core, EMC, F5, Meraki, Norkia, QTC, Supermicro, and Other Open Switches.

1. What is a DAC cable?

Direct Attached Cables, or DACs, are copper cable assemblies made from twinax cable, terminated with transceiver housings on each end. DACs are available in passive or for active variants.

2. What is the difference between SFP and DAC?

SFP is a modular transceiver that can be used with different types of cables, while DAC is a cable assembly that directly connects networking equipment without the need for transceivers.

Polybag Includes

• DAC SFP+ cable: 1 pc
• Warranty card: 1
